平板式初效过滤器
产品特性:
* 滤料为优质合成纤维, 容尘量大,阻力低；
* 使用寿命长，成本低廉；
* 耐湿度可达100%； 耐温80℃；
* 捕集5μm以上的颗粒尘埃及各种悬浮物；
用途:
空调过滤系统预过滤和二级过滤； 洁净室进风或回风过滤； 可以提高中高效过滤器的使用寿命。
Panel filter
Specialty:
* Panel filter is processed by high quality fiber and featured with high dust holding, low resistance. The frame is metal or cardboard and can be replaced easily.
* The powder coating wires outside increase the working life.
* Temperature resistance: 80℃, relative humidity is 100%.
Application:
Panel filter is used for the air-Condition filtration system and clean room. It can lengthen the working life of the medium & high efficiency filter.
技术参数: Specification
|
型号
Type
|
尺寸Size
宽x高x厚
(mm)
|
额定风量Rated Air Flow (m3/h）
|
初阻力 Initial Pressure Drop (Pa)
|
计重效率Average Arrestance
|
防护网
|
外框
Frame
|
滤料
Media
|
|
FX-BS-G2
|
595x595x21
|
3200
|
30
|
85%
|
双面喷塑方格网
|
纸框
Cardboard铝合金框Aluminum alloy
镀锌框
Galvanized sheet
|
G2/G3/G4合成纤维、无纺布
|
|
295x595x21
|
1600
|
30
|
85%
|
|
FX-ZD-G3
|
595x595x46
|
3200
|
35
|
95%
|
镀锌菱形网
|
|
295x595x46
|
1600
|
35
|
95%
|
|
FX-ZD-G4
|
595x595x46
|
3200
|
35
|
95%
|
加强钢筋
|
|
295x595x46
|
1600
|
35
|
95%
|
注:可根据需要定制不同规格. Note: Special Size Available Upon Request.
