真空低温固体连续干燥机
VACUUM BELT DRYER FOR POWDER/PARTICLE
产品介绍 Introduction
真空低温固体连续干燥机的开发来源于全国客户的需求，我公司在大量销售真空低温液体连续干燥机的过程中，得到了全国制药、化工、食品行业客户对该产品的需求信息。通过和客户的交流，使我们了解到目前国内固体粉末颗粒干燥的现状，传统干燥工艺存在的问题已经制约了企业产品质量的提升和企业的发展，更感受到这些行业对先进干燥设备的追求和渴望。
经过我们几年的努力，开发的真空低温固体连续干燥机通过国内几十家用户的实际运行结果，为他们彻底解决了干燥时间长、干燥温度高、干燥工艺复杂、温度难控制、劳动强度大、产品易污染、自动化操作难实现、品质无法提高等问题。该设备特别对那些要求干燥工艺温度低、干燥时间短、要求干燥后的产品溶剂含量极低、溶剂可回收、有效成分的保存更是***佳选择。
The development of the vacuum belt dryer for powder/particle is to meet the requirements coming from our domestic clients, we got this need information while we sold our vacuum belt dryer for liquid/paste to our clients in the areas of pharmacy、chemical、foodstuff. We knew the present status of drying of solid powder/particle by communication with them, and realized that techniques of traditional dryers had limited the promotion of the quality of their products and further development of the companies, we felt the pursue and desire of the people in these areas for advanced drying equipment
After several years of our efforts, the vacuum belt dryer for powder/particle has passed the actual running of dozens of domestic clients, thoroughly solved their problems of long time drying、high drying temperature、complicated drying process、difficult in temperature control、strong labor force、easy pollution of the products、no auto operation、no promotion of the quality of the products. Our dryer is especially suitable for the products which need low drying temperature 、 short drying time、extreme low solvent content 、recovery of the solvent、best choice for preservation of active ingredient.
技术原理 Technical Principle
根据客户产能的大小，在真空容器内设计布置3-11层传送带，通过连续固体进料器和布料器，将客户所需要干燥的原料在真空条件下实现连续送料，并均匀的布放在干燥带上，由于物料在干燥过程中不断翻动，所以加快了蒸发速度和时间，保证产品在干燥过程中的均匀性，干燥的温度在20-150℃可调，物料从进入干燥机到干燥后出料约20-80分钟可调。干燥后的产品如需粉碎工艺，可在真空条件下粉碎，避免了粉尘飞扬，增加了产品收率和解决了污染等问题。干燥后的产品通过真空连续出料器和真空收料机实现连续出料，同时可实现有机溶剂的回收，解决了环保问题并增加溶剂回收收益。
According to the capacity needed of our clients, we arrange 3-11 layers of conveying belts inside our vacuum container, after passing continuously through the solid inlet and distributing device, the wet material will be dried under the vacuum condition by continuous feeding-in, distributed evenly on the drying belt. Because of the constant turning of the material during the drying process, so this quickens the evaporation speed and shortens the drying time, and also guarantees the homogeneity of the product during the drying process, the drying temperature can be adjusted between 20-150 ℃,The drying time from the feeding-in of wet material to the discharging of dried product can also be adjusted around 20-80 minutes. If the dried product needs to be comminuted, it can be comminuted under the vacuum, so no dust explosion, thus increasing the recovery rate and also solving the problem of pollution. The dried product will be discharged continuously by pneumatic conveying systems and vacuum storage bin, and in the same time recovering the organic solvent, so as to solving the environmental problems and adding the profit by organic solvent recovery.
适用范围 Application scope
1.中药、西药、食品、化工等企业
2.各种固体、结晶体、颗粒、粉末、丸剂、果品等原料
3.易氧化、易爆、强刺激、剧毒物料
4.需要回收各种溶剂的产品
1. Enterprise like Chinese medicine、western medicine、foodstuff、chemistry, etc.
2. Various kinds of solid, crystal, particle, powder, pills, fruit, etc.
3. Material of easy oxidation 、easy explosion、strong stimulation、violent in toxicity.
4. Material requires solvent recovery.
设备优点Equipment advantage
1. 实现真空条件下连续进料连续出料
2. 实现干燥工艺自动化、连续化、管道化
3. 干燥工艺温度在20-150℃可调
4. 运行成本是传统干燥工艺的三分之一
5. 产品收率达到99%以上
6. 干燥时间20-80分钟可调
7. 大大降低劳动力成本
8. 采用PLC自动控制系统
9. 减少了干燥工艺复杂造成产品污染的环节
10. 实现产品干燥过程中溶剂回收要求
11.在线自动清洗，符合GMP要求。
1. Continuous feeding-in and discharging in the vacuum state
2. Automatic, continuous, channelization during drying process
3. Temperature adjusted from 20-150℃
4. The running cost is only 1/3 of the traditional technology
5. Product yield can reach 99%
6. Continuous discharging within the drying time 20-80 minutes adjustable
7. Reducing the labor cost greatly
8. Adopting PLC automatic control system
9. Reducing the pollution of the product by simplifying the complex of drying process
10. Satisfying the need of recovery of the solvent during the drying process
11. CIP cleaning, in accordance with GMP standards
