1）DR2.DR4,DR10 特点
l DR2产水量为0-3t/h;DR4产水量为3-6t/h.DR10产水量为 6-12t/h.
l DR单罐软化阀为浮动床，省盐、省水、省树脂、高硬水软化。
l 流量/时间双控模式 流量模式下，所有工位均按设定水量递减到“零”自动切换
l 进水压力低，具有停水、停电记忆功能。
l 可设定流量控制下的“强制时钟再生”即“延时再生”。
l 阀芯采用平面陶瓷密封。
Characteristics of DR2.DR4 and DR10
l It adopts the backflow regeneration controlling principle floating bed.The quality of water is high whereas the consumption of salt is low.
l No hard water runs through the equipments for the industrial type.It is suitable in some situations where the requirements for the quality of water are high,such as boilers.
l The sealing for the core of planar valve adopts ceramic non-wear type and guarantees reliable usage.
l The Chinese(or English) operating interface shows the instant and accumulated amount of water.
l There are two modes to choose from:full-flow pattern and time mode.It has the memory function of cutting off the electricity and water.
l It's easy to be installed and adjusted and needs no operation from the user.
l It can be forced to be set regeneration time of day in flow pattern.
2）参数表
|
|
|
|
|
|
|
|
流量T/H
|
|
|
|
|
1
|
DR2A
|
|
|
6分
|
6分
|
|
1-3
|
|
2
|
DR2B
|
|
|
6分
|
6分
|
|
1-3
|
|
3
|
DR4A
|
|
|
1寸
|
1寸
|
|
3-6
|
|
4
|
DR4B
|
|
|
1寸
|
1寸
|
|
3-6
|
|
5
|
DR10
|
|
|
1.5寸
|
1.5寸
|
|
8-12
|
Parameter table
|
Model
|
Display
Method
|
Function
|
Water-in-out Mouth (mm)
|
Central Pine (mm)
|
Control Method
|
Flow（T/H)
|
|
Flow
|
Time
|
|
DR2A
|
Digital
|
Softening
|
20
|
20
|
Double-control Pattern
|
1-3
|
|
DR2B
|
LCD
|
20
|
20
|
Double-control Pattern
|
1-3
|
|
DR4A
|
Digital
|
33.3
|
33.3
|
Double-control Pattern
|
3-6
|
|
DR4B
|
LCD
|
33.3
|
33.3
|
Double-control Pattern
|
3-6
|
|
DR10
|
LCD
|
50
|
50
|
Double-control Pattern
|
8-12
|
