型号Model |
HYQJ200×1S-100×4N |
HYQJ200×2S-100×8N |
HYQJ250×2S-100×12N |
HYQJ250×3S-100×20N |
|
处理量Treatment Capacity |
60m³ |
120m³ |
240m³ |
320m³ |
除砂旋流器尺寸
Desander Cyclone Specs |
8in |
10in |
除砂旋流器数量
Desander Cyclone Qty |
1nos |
2nos |
2nos |
3nos |
除泥旋流器尺寸
Desilter Cyclone Specs |
4in |
除泥旋流器尺寸
Desilter Cyclone Qty |
5nos |
8nos |
12nos |
20nos |
|
工作压力Working Pressure |
0.25～0.4mpa |
|
进浆口直径Inlet Size |
DN125mm |
DN150mm |
DN150mm |
DN200mm |
|
出浆口直径Outlet Size |
DN150mm |
DN200mm |
DN200mm |
DN250mm |
|
分离点Separation Point |
15μm～44μm |
|
底流筛型 Bottom Shaker |
HYZS60/N/A |
HYZS752/N/A |
HYZS752/N/A |
HYZS703/N/A |
|
外形尺寸Dimension |
1510×1160X2000mm |
1835×1230×1810mm |
1835×1230×1810mm |
2419×2150×2147mm |
|
重量Weight |
600kg |
980kg |
1250kg |
2350 kg
|
