智能后视镜ACC检测OBD线束
智能后视镜ACC检测OBD线束采用插头式工业设计，ACC检测到信号后对智能后视镜输出信号，便于智能后视镜领域安装方便，智能OBD线束为智能后视镜提供ACC信号，供电及数据。
n 智能后视镜ACC检测OBD线束架构设计
内部架构处理为多核分布式处理，OBD 解码数据处理与主控 MCU 分离，保证 ACC 信号检测数据读取精准、计算有效；
n 引领智能后视镜ACC检测OBD线束趋势设计
智能 OBD 插头自适应当前先进技术（支持发动机自动启停、支持多 CAN 等黑科技），支持实智能后视镜 ACC 检测 OBD 插头时数据获取，驾驶习惯数据获取，熄火自动生成本次行程报告，详见 OBD-TT 数据流；
n 智能后视镜ACC检测OBD线束参数及保护设计
采用 TVS 保护、输入反接保护、CAN 总线保护、低电压保护、串口电平保护多重机制；
n 智能后视镜ACC检测OBD线束休眠唤醒设计
采用低功耗休眠、点火唤醒、总线唤醒、Gsensor 唤醒（定制）、震动唤醒、串口唤醒（定制） ；
n 电气参数设计
输入电压： 12V
输出电流： 3A
输入输出转换： 直通
***高输入电压： 40V
n 智能后视镜ACC检测OBD线束处理器设计
采用 32 位单片机
n 智能后视镜ACC检测OBD线束CAN总线设计
OBD 及 CANBUS 部分采用标准协议，私有协议带车身状态的为 EST560-mini6。
在标准协议数据下，支持 CAN 总线协议和 K 线协议，可有效采集总线上的数据，针对市面上的车型，采用协议自动匹配。OBD 支持远程升级，我们采用的是云服务器 OTA 升级。
OBD 有效采集发动机数据、采用请求获取的方式，有效检测总里程数据、油耗、故障码。
EST560 带有车身数据、钥匙状态和远程控制。
Smart Rearview Mirror ACC test OBD harness the plug type of industrial design, the ACC for smart rearview mirror output signal after detecting, facilitate Smart Rearview Mirror convenient installation, intelligent OBD harness for Smart Rearview Mirror to provide ACC signals, power supply and data.
n Smart Rearview Mirror ACC test OBD harness architecture design
Processing multicore distributed processing, internal structure, separating from the main control MCU OBD decoding data processing, to ensure that the ACC signal detecting data read accuracy, computational efficient;
n lead Smart Rearview Mirror ACC test OBD harness design trend
Intelligent OBD plug adaptive current advanced technology (support automatic engine start-stop, support for multiple CAN black science and technology), support real smart rearview mirror ACC test OBD plug in data acquisition, data acquisition driving habits, shut down automatically generate the trip report, see the OBD - TT data flow;
n Smart Rearview Mirror ACC test OBD wire parameters and protection design
The TVS protection, input reverse connection protection and CAN bus protection, low voltage protection, serial ports, multiple level protection mechanism;
n Smart Rearview Mirror ACC test OBD harness sleep wake up design
With low power consumption of dormancy, ignition sensei, bus sensei, Gsensor sensei (custom), vibration sensei, serial ports, wake up (custom);
n electrical parameter design
The input voltage: 12 v
Output current: 3 a
Input/output transformation: straight through
The highest input voltage: 40 v
n Smart Rearview Mirror ACC test OBD harness processor design
Using 32-bit MCU
n Smart Rearview Mirror ACC test OBD wiring harness CAN bus design
OBD and CANBUS part adopts standard protocol, a private agreement with the state of the body for EST560 - mini6.
Under the standard protocol data, support CAN bus protocol and the K line, which CAN effectively collect the data on the bus, in view of the models on the market, adopts automatic matching of agreement. OBD support remote upgrade, we adopt the OTA upgrade is cloud server.
OBD effective engine data, with the method of request, effective detection, fuel consumption, total mileage data fault code.
EST560 with body data, the key state and remote control.
