适用范围 Aplication
|
|
1区、2区危险场所。
ⅡA、ⅡB类爆炸性气体环境。
Can be used in Zone 1 and Zone 2 dangerous places.
Can be used in IIA、IIB、group explosive atmosphere.
|
|
|
型号含义 Model implication
|
|
|
|
主要技术参数 Main technical parameters
|
型号 额定电压(V) 脱扣器额定电流(A) 防爆标志 电缆外径() 进线口螺纹() 防护等级
Type Rated voltage Rated current of release Ex-mark Cable's outer Inlet's thread Protection class
diameter
CBK52-32 1、2、3、4、6、10、16 12-17 1
20、25、32
CBK52-63 40、50、63 Exde II Bt6 13-26 1'/2、2 Ip54
CBK52-100/□ 80、100 18-33 1'2、2 *Ip55
CBK52-225/□ 380/220 125、160
180、200、225 27-42 2、2'/2
CBK52-400/□ 250、315 34-50 3
350、400
CBK52-630/□ 500、630 43-60 3、3'/2、4
|
|
产品特点 Features
|
■ 铸铝合金外壳，表面喷塑 ◆ Diecasted aluminium alloy shell with
■ 内装高分断小型断路器或低压塑壳式断路器. ◆ Inside is installed minicircuit breaker of high breaking
capacity or The inside packs a footlight tube,the fleetness
starts starts in a moment,can according to customer request
refit the one foot light tube.
■ 具有过载,短路保护功能,也可根据要求加装 ◆ With overload and shortcircuit protection,leakage protection is
■ 漏电分励脱扣等保护装置. ◆ Available as required Cent the the takes off to button up the
etc.protection device.
■ 钢管或电缆布线均可. ◆ Suitable for steeel pipe and cable wiring.
■ 符合GB3836-2000.IEC60079标准要求. ◆ Suitable for GB3836-2000,IEC60079 standard request.
|
|
外形举例 Outline example
|
|
|
|
|
|
CBK52-32 (IIB)
|
CBK52-225 XD (IIB)
|
|
|
|
|
CBK52-60 (IIB)
|
CBK52-225XX(IIB)
|
|
|
|
|
CBK52-100 (IIB0
|
|
|
外形举例 Outline example
|
|
|
|
|
CBK 52-400XD (IIB)
|
CBK52-400XX (IIB)
|
|
|
|
|
CBK 52-630XX (IIB)
|
CBK 52-630XD (IIB)
|
|
|
